起重機安全距離和主梁撓度國家標準
2011/6/13 14:21:48
起重機安全距離和主梁撓度國家標準
| 起重機安全距離和主梁撓度國家標準 |
| Standard for Crane Safty Clearance and Deflection |
| |
|
|
|
| |
|
|
中國國家標準號 |
| CXTS 單梁起重機安全距離 |
|
China Standard |
| Clearance for single girder crane |
|
|
| |
|
|
|
| 起重量 |
起重機頂到屋頂最低點距離 |
起重機端側到廠房側墻面距離 |
|
| Load (T) |
Clearance to ceiling (mm) |
Clearance to wall (mm) |
|
| 1~16 |
200 |
100 |
JB/T1306-94 |
| |
|
|
|
| |
|
|
|
| CXTD 雙梁起重機安全距離 |
|
|
| Clearance for double girder EOT crane |
|
| |
|
|
|
| 起重量 |
起重機頂到屋頂最低點距離 |
起重機端側到廠房側墻面距離 |
|
| Load (T) |
Clearance to ceiling (mm) |
Clearance to wall (mm) |
|
| 5~25 |
300 |
80 |
GB7592-87 |
| 32~50 |
400 |
80 |
GB7592-87 |
| 63~125 |
400 |
100 |
GB7592-87 |
| 160~250 |
500 |
100 |
GB7592-87 |
| |
|
|
|
| |
|
|
|
| 滿載時允許最大垂直撓度 |
S = 跨度 Span |
|
| Max. allowed vert. Deflection with load and trolley |
|
| |
|
|
|
| 1. CXTD 雙梁橋式起重機 |
|
|
| CXTD Double girder EOT crane |
|
|
| A1-A3 |
S/700 (0.00142xS) |
|
GB/T14405-93 |
| A4-A6 |
S/800 (0.00125xS) |
|
|
| A7 |
S/1000 (0.001xS) |
|
|
| |
|
|
|
| 2. CXTS 單梁橋式起重機 |
|
|
| CXTS Single girder crane |
|
|
| A3-A5 |
S/800 (0.00125xS) |
|
JB/T1306-94 |
| |
|
|
|
| 3. CXTU 單梁懸掛起重機 |
|
|
| CXTU Single girder under running crane |
|
|
| A3-A5 |
S/700 (0.00142xS) |
|
JB/T2603-94 |
